XTI | 2.0 Square IP66 | IK11

PRODUCT OVERVIEW

XTI 2.0 Square IP66 IK11 – Size: 60mm Wide x 70mm High integral gear continuous

XTI 3 0 Square IP66 IK10 Bottom View

The XTI series is an IP66 / IK11 profile that is capable of 50ºC ambient locations and, with the installation of the Xeramix R system, has a 15 year warranty

FEATURES
the XTI profile has a continuous ribbon diffuser that has no joins or breaks. This industry first profile can house ancillary components such as speakers and emergency packs and can be mounted directly to the surface, suspended or with custom brackets designed on application.

XTI 2 0 Square Front view
Proformax S combined logo
DATA TABLE
Output
4ft Length
1120mm
Luminous Flux
(Delivered Lumens)
LO
1900
HO
3500
Xeramix CRI 80+
Lumen Maintenance 114,000 hours [L90 B10 @ 50°C]
Proformax
Proformax S
CRI 90+
Lumen Maintenance 114,000 hours [L90 B10 @ 50°C]
Warranty Xeramix 10 years
Proformax / Proformax S 7 years
Electrical Power Consumption Between 20 and 45w/m
Voltage input range 120 – 277V
Control methods Dimming options for white light: 0-10V, DALI, DMX Optional RGB / Sunset Dimming control DMX or DALI XI
Total harmonic distortion THD 9.8% max
Approvals UL / CE / CCC / AS:NZS / EMC
Physical Dimensions 60 X 70 mm
Weight per metre 4.1kg (9Ibs) average weight
Housing Aluminium Extrusion with: Standard – silver powder-coat, black or white textured, (or) optional selected powder-coated finish
Diffuser Opaque Polycarbonate Diffuser / Clear Polycarbonate Diffuser / Parabolic Louvre
Connections Optional polarised electrical connection between sections
Compatible ceiling type Suitable for gyprock (drywall) ceilings, metal pan, concrete, timber and T-bar grid ceilings
Mounting Field adjustable rollerball wire suspensions / rod suspensions / wall mounting / surface mount / custom Mounting
Joiner options 90º/ Straight / 180º/ Custom
Operating temperatures Xeramix = -25ºC to 50ºC (-13ºF to 140ºF)
Proformax = -25ºC to 35ºC (-13ºF to 95ºF)
Proformax S = -25ºC to 35ºC (-13ºF to 95ºF)
Environment IP66 (not in direct sunlight) (diffuser must not face upwards)
Minimum length adjustment Xeramix = 1mm, Proformax = 25mm, Proformax S = 140mm
LED board types Xeramix LED boards in 25mm / 100mm / 280mm / 560mm lengths Zhaga compatible
Proformax LED boards in 50mm / 280mm / 560mm lengths Zhaga compatible
Proformax S LED boards in 140mm / 280mm / 560mm lengths Zhaga compatible
IK rating IK11
Vandal proof Available with anti-vandal fasteners
Optional extras Lanyards / Emergency packs / Camera / Environmental plugs / Thermal throttle / IOT connectivity
XTI lengths table
DESCRIPTION
LENGTHS
total luminaire length in mm 578 858 1138 1418 1698 1978 2258 2538 2818 3098 3378
total luminaire length in inches 23 34 45 56 67 78 89 99 111 122 133
‘560 board multiples 1.0 1.5 2.0 2.5 2.0 3.5 4.0 4.5 4.5 5.5 6.0
EXAMPLE OF STANDARD LENGTH COMBINATION
XTI R combination length

CREATING LENGTHS WITH XTI | 2.0 Square IP66 IK11

The XTI | 2.0 IP66 IK11 set lengths can be coupled together in any combination to achieve the desired length.
Note: custom lengths are also available – please consult your local Xero office for information

CUSTOM LENGTHS

Custom lengths Xeramix = 25mm / Proformax = 25mm / Proformax S = 140mm

The XTI | 2.0 Xero Linear Lighting System brings high-quality dot free illumination to commercial and institutional interior environments. Featuring the latest generation of LED technology, The XTI | 2.0 is the perfect choice for offices, retail and public spaces with clean, uninterrupted lines of light that comes from Xero’s exclusive patent ‘SpeedConnect’ System

L80 B10 82,000 hours @35ºC
Proformax boards are CRI 90 as standard and have the highest efficiency currently on the market. The Proformax boards also have the lowest sulfurisation deteriorisation compared to other plastic based chips on the market.

L80 B10 82,000 hours @35ºC
Proformax boards are CRI 90 as standard and have the highest efficiency currently on the market. The Proformax boards also have the lowest sulfurisation deteriorisation compared to other plastic based chips on the market.

L90 B10 114,000 @ 50˚C
Xeramix 1 boards are both high output and high efficiency combined giving unmatched flexibility, by tuning the drive current any output is achievable

3000k_symbol4000k_symbol5000ktuneable-white_symbolcyanosis_symbolrgb_symbolrgbw_symbol

Joining Configuration IMG 1 1

CREATING LENGTHS WITH XTI | 2.0 Square IP66 IK11

The XTI | 2.0 IP66 IK11 set lengths can be coupled together in any combination to achieve the desired length.
Note: custom lengths are also available – please consult your local Xero office for information

Down Optics



click on selection above to view larger image

MOUNTING OPTIONS XTI R SERIES 4

90o Butt bend icon1         Tee Butt bend icon1

Unlit butt bends only



* Other options including custom colour matching available on request
Contact your nearest Distributor – xerolighting.com/contact

STANDARD COLOURS
* No additional cost
Textured White  90133641 Textured White90133641
Precious Silver  9717043K Precious Silver9717043K
Textured Black  90132679 Textured Black90132679
RAL COLOURS
* Additional cost
RAL 9010
Pure White Satin
  PR12/40197/CS1
RAL 9010
Pure White Satin
PR12/40197/CS1
RAL 7035
Light Grey Satin
  PR12/60978/CS1
RAL 7035
Light Grey Satin
PR12/60978/CS1
RAL 9003
Signal White Satin
  PR12/40197/CS1
RAL 9003
Signal White Satin
PR12/40197/CS1
RAL 1015
Light Ivory Gloss
  PR12/941/C72
RAL 1015
Light Ivory Gloss
PR12/941/C72
RAL 7032
Pebble Grey Satin
  PR12/60232/CS2
RAL 7032
Pebble Grey Satin
PR12/60232/CS2
RAL 6002
Leaf Green Gloss
  PR12/20726/C12
RAL 6002
Leaf Green Gloss
PR12/20726/C12
RAL 9005
Jet Black Gloss
  PR12/710/C42
RAL 9005
Jet Black Gloss
PR12/710/C42
RAL 9004
Signal Black Matt
  PR18/7120/CM3
RAL 9004
Signal Black Matt
PR18/7120/CM3
RAL 5012
Light Blue Satin
  PR12/30670/CS5
RAL 5012
Light Blue Satin
PR12/30670/CS5
RAL 5005
Signal Blue Satin
  PR12/30263/CS6
RAL 5005
Signal Blue Satin
PR12/30263/CS6
RAL 1021
Colza Yellow Satin
  PR12/60464/CS6
RAL 1021
Colza Yellow Satin
PR12/60464/CS6
RAL 1018
Zinc Yellow Gloss
  PR12/159/C46
RAL 1018
Zinc Yellow Gloss
PR12/159/C46
RAL 1003
Signal Yellow Gloss
  PR12/134/C36
RAL 1003
Signal Yellow Gloss
PR12/134/C36
RAL 2000
Yellow Orange Gloss
  PR12/650/C38
RAL 2000
Yellow Orange Gloss
PR12/650/C38
RAL 2009
Traffic Orange Gloss
  PR12/6162/C21
RAL 2009
Traffic Orange Gloss
PR12/6162/C21
ANODISED FINISHES
(Not available for curved profiles)
* Additional cost
25 micron Annodised   25 micron Annodised
Grey Anodised   Grey Anodised
Black Anodised   Black Anodised
Green Anodised   Green Anodised
Gold Anodised   Gold Anodised
Blue Anodised   Blue Anodised
Red Anodised   Red Anodised
NON-STANDARD COLOURS
GROUP 1 COLOURS
* Additional cost
alphatec classic white gloss  27281880 alphatec classic white gloss27281880
10 Micron Anodised Aluminium
(Not available for curved profiles)

10 Micron Anodised Aluminium
(Not available for curved profiles)
APO Grey Scylla  90136612 APO Grey Scylla90136612
Black Scylla  90150003 Black Scylla90150003
Horizon White Scylla  90151608 Horizon White Scylla90151608
Mid Bronze Matt  27251014 Mid Bronze Matt27251014
Metropolis Silver Glow Gloss  97184623 Metropolis Silver Glow Gloss97184623
Notre Dame Scylla  90150223 Notre Dame Scylla90150223
Onyx Pearl Gloss  97152052 Onyx Pearl Gloss97152052
Pewter Pearl Satin  97188202 Pewter Pearl Satin97188202
Silver Grey Matt  27251272 Silver Grey Matt27251272
Steel pearl Satin  97157127 Steel pearl Satin97157127
Zincshield Matt  9907036M Zincshield Matt9907036M
Shoji White Satin  27284682 Shoji White Satin27284682
Charcoal Gloss  2729086G Charcoal Gloss2729086G
Olde Pewter Satin  27250243 Olde Pewter Satin27250243
Cottage Green Satin  27284219 Cottage Green Satin27284219
APO Grey Satin  27232786 APO Grey Satin27232786
Berry Grey, Gloss  2727262G Berry Grey, Gloss2727262G
JASPER satin  2728122S JASPER satin2728122S
black CB night sky satin  95981878 black CB night sky satin95981878
black satin  90109024S black satin90109024S
Black Gloss  2729090G Black Gloss2729090G
Black Matt  27219319 Black Matt27219319
blue ridge satin  27288480 blue ridge satin27288480
bright white gloss  27284636 bright white gloss27284636
charcoal satin  27288351 charcoal satin27288351
classic cream satin  2722095S classic cream satin2722095S
dark grey Matt  27251275 dark grey Matt27251275
deep brunswick green  2726134G deep brunswick green2726134G
deep ocean satin  2725125S deep ocean satin2725125S
dune satin  2723087S dune satin2723087S
duralloy white satin  2721139S duralloy white satin2721139S
evening haze satin  2723055S evening haze satin2723055S
ironstone satin  2727257S ironstone satin2727257S
manor red satin  2724134S manor red satin2724134S
monument matt  9599066M monument matt9599066M
monument satin  2729067S monument satin2729067S
natural pearl matt  97189119 natural pearl matt97189119
notre dame gloss  27236672 notre dame gloss27236672
olde pewter satin  26050243 olde pewter satin26050243
oyster matt  27236858 oyster matt27236858
paperbark satin  2723088S paperbark satin2723088S
pearl white gloss  2721114G pearl white gloss2721114G
primrose gloss  27284365 primrose gloss27284365
rivergum beige gloss  27236991 rivergum beige gloss27236991
shale grey satin  27283246 shale grey satin27283246
stone grey satin  27278126 stone grey satin27278126
surfmist satin  2721137S surfmist satin2721137S
wedgewood satin  27250279 wedgewood satin27250279
white birch gloss  27237131 white birch gloss27237131
wilderness satin  27284224 wilderness satin27284224
windspray satin  2727256S windspray satin2727256S
woodland grey satin  272255S woodland grey satin272255S

GROUP 2 COLOURS
* Additional cost and minimum quantity required
alphatec blaze blue gloss  98419941 alphatec blaze blue gloss98419941
alphatec french blue gloss  98432725 alphatec french blue gloss98432725
alphatec pommel blue gloss  98451034 alphatec pommel blue gloss98451034
alphatec space blue gloss  98419990 alphatec space blue gloss98419990
alphatec navy gloss  98450282 alphatec navy gloss98450282
alphatec dark violet gloss  98451926 alphatec dark violet gloss98451926
alphatec flame red gloss  98419959 alphatec flame red gloss98419959
alphatec signal red  98450735 alphatec signal red98450735
safety yellow gloss  9842015G safety yellow gloss9842015G
alphatec yellow gold gloss  98433617 alphatec yellow gold gloss98433617
alphatec lemon yellow gloss  98432120 alphatec lemon yellow gloss98432120
alphatec orange x15 gloss  98451439 alphatec orange x15 gloss98451439
alphatec mistletoe gloss  98451040 alphatec mistletoe gloss98451040
alphatec transformer grey gloss  98432186 alphatec transformer grey gloss98432186
Aztec Black  90182757 Aztec Black90182757
Aztec Silver  90185040 Aztec Silver90185040
Copper Kinetic Pearl Satin  9717183K Copper Kinetic Pearl Satin9717183K
Graphite Sarouk  93551677 Graphite Sarouk93551677
Grey Hammer  90185184 Grey Hammer90185184
Gunmetal Kinetic Pearl Satin  9718115K Gunmetal Kinetic Pearl Satin9718115K
Light Grey Scylla  90150766 Light Grey Scylla90150766
Platypus Kinetic Pearl Satin  9717214K Platypus Kinetic Pearl Satin9717214K
Red Brown Scylla  90185473 Red Brown Scylla90185473
Silver Glow Pearl Gloss  97184623 Silver Glow Pearl Gloss97184623
Silver Lode Pearl Texture  9017034Z Silver Lode Pearl Texture9017034Z
Silver Sarouk  93584874 Silver Sarouk93584874
St Elmos Fire Kinetic Pearl Satin  9717208K St Elmos Fire Kinetic Pearl Satin9717208K
Stone Beige Scylla  90185474 Stone Beige Scylla90185474
Storm Grey Scylla  90150183 Storm Grey Scylla90150183
clear gloss  91081797 clear gloss91081797
White Matt  96132312 White Matt96132312
Magnolia Gloss  27232658 Magnolia Gloss27232658
Metropolis Storm Satin  97184684 Metropolis Storm Satin97184684
Primrose Scylla  9013005Z Primrose Scylla9013005Z
Classic Hawthorn Green Gloss  27233709 Classic Hawthorn Green Gloss27233709
Mannex Suede, Texture  90137543 Mannex Suede, Texture90137543
Citi Matt  97188471 Citi Matt97188471
armourspray velocity green  91033709 armourspray velocity green91033709
armourspray white gloss  91019143 armourspray white gloss91019143
barley gloss  2723089G barley gloss2723089G
barrister white satin  27284672 barrister white satin27284672
black Sarouk  93551146 black Sarouk93551146
blue Hammer  90185159 blue Hammer90185159
bright silver metallic gloss  96151491 bright silver metallic gloss96151491
canola cream satin  27281796 canola cream satin27281796
champagne Kinetic Matt  9713059K champagne Kinetic Matt9713059K
charcoal Metallic Pearl Gloss  97118796 charcoal Metallic Pearl Gloss97118796
copper satin  9614137Q copper satin9614137Q
light grey gloss  2727263G light grey gloss2727263G
magnolia Scylla gloss  90133618 magnolia Scylla gloss90133618
off white satin  27233732 off white satin27233732
precious nickel pearl matt  97188360 precious nickel pearl matt97188360
riversand matt  95936656 riversand matt95936656
streetwise silver satin  9107049Q streetwise silver satin9107049Q
surfmist matt  95984758 surfmist matt95984758
weathered copper matt  27233724 weathered copper matt27233724
woodland grey matt  95951698 woodland grey matt95951698
X | TEK PREMIUM FINISHES
Concrete Finishes
* Additional cost
Charcoal Concrete   Charcoal Concrete
Polished Concrete   Polished Concrete
Light Concrete   Light Concrete


Rust Finishes

* Additional cost
Desert Sand   Desert Sand
Edgy Auburn   Edgy Auburn
Earthy Ochre   Earthy Ochre
Morrocan Spice   Morrocan Spice

Woodgrain Finishes

* Additional cost
Antique White   Antique White
Natural American Oak   Natural American Oak
Dark Mocha   Dark Mocha
Driftwood   Driftwood
European Walnut   European Walnut
Natural Blackbutt   Natural Blackbutt
Natural Bush Cherry   Natural Bush Cherry
Natural Casuarina   Natural Casuarina
Natural Chestnut   Natural Chestnut
Natural Curly Birch   Natural Curly Birch
Natural Ebony   Natural Ebony
Natural French Oak   Natural French Oak
Natural Golden Gum   Natural Golden Gum
Natural Golden Oak   Natural Golden Oak
Natural Ironbark   Natural Ironbark
Natural Jarrah   Natural Jarrah
Natural Kwila   Natural Kwila
Natural Maple   Natural Maple
Natural Silky Oak   Natural Silky Oak
Natural Snow Gum   Natural Snow Gum
Natural Tasmanian Oak   Natural Tasmanian Oak
Natural Teak   Natural Teak
Natural Wenge   Natural Wenge
Smoked Ash   Smoked Ash
Walnut Burl   Walnut Burl
Weathered Timber   Weathered Timber
Western Red Cedar   Western Red Cedar
Rose Mahogany   Rose Mahogany
African Blackwood   African Blackwood
Coastal Spotted Gum   Coastal Spotted Gum
Merbau   Merbau
Charred Timber   Charred Timber
Blue Ash   Blue Ash
Brushbox   Brushbox
White Ash   White Ash
Hampton Beech   Hampton Beech

0-10v_symboldali-control-gear_symboldsi-compatible_symboldmx_symboldimmer-switch_symbolconstant-light-output_symbolmotion-sensor_symbolripple-free_symbolbluetooth_symbol

eess_symbolrcm-reg-mark-compliance_symbolssl_symbolccc_symbolce_symbolETL_approval.x24248 XTA | 1.5 Beam IP55

DATA SHEET Icon
photometrics_symbol
sDoc EMC icon
sDoc IP66 icon
sDoc IK10 icon
cad-drawing_symbol
data-sheet_symbol
brochure_symbol
brochure_symbol
xta-1-5-beam-product-image
Wire Suspension Symbol

meet the family

XTI logo

XTI | 2.0 series

XTI 2 0 rec TILE
XTI 2 0 slot TILE
XTI 2 0 square TILE
